Inline Cema - Size specifics and compliance

pioneer conveyor - cema compliance
click by row for more detail
Belt Width Trough Angle
E Max
Dia 4 Dia 5 Dia 6
H Max
Dia 4 Dia 5 Dia 6
K +/- 1/4"
Dia 4 Dia 5 Dia 6
1820
10.7511.250
22.522.50
88.50
1835
12.5130
21213
88.50
2420
11.51212.75
28.528.527.5
88.59
2435
13.7514.2514.75
26.526.525
88.59
3020
12.512.7513.5
34.534.533.5
88.59
3035
1515.516
323230.5
88.59
3620
13.2513.514.25
40.540.539.5
88.59
3635
16.2516.7517.25
37.537.536
88.59
4220
1414.515.25
46.546.545.5
8.599.5
4235
17.7518.2518.75
434341.5
8.599.5
4820
1515.516.25
52.552.551.5
8.599.5
4835
1919.7520
48.548.547
8.599.5
5420
16.7516.517.25
58.558.557.5
8.759.259.75
5435
20.252121.25
494947.5
8.759.259.75
6020
17.7518.519.25
64.564.563.5
8.759.259.75
6035
21.522.2522.5
59.559.558
8.759.259.75
